Chevrolet Cruze Wheel Hub Unit OE Number 13591998
This GM Genuine Part/ACDelco GM Original Equipment Wheel Bearing and Hub Assembly supports the vehicle while allowing the wheel to rotate, and are GM-recommended replacements for your vehicle's original components.
Basic Information
- OE Number: 13591998
- Supersession(s): Replaces 13500573, 13502872, 13580090, 13598921
- Part Name: Rear Wheel Hub and Bearing Assembly with Wheel Studs (also known as Hub Assembly, Rear Wheel)
- Brand: GM Genuine Parts / ACDelco GM Original Equipment
- Position: Right Rear and Left Rear (both sides)
- Vehicle Application: Chevrolet Cruze (2011-2016), Chevrolet Cruze Limited (2016) with drum brakes and disc brakes
Official Description
This GM Genuine Part/ACDelco GM Original Equipment Wheel Bearing and Hub Assembly supports the vehicle while allowing the wheel to rotate, and are GM-recommended replacements for your vehicle's original components. It features:
- Maximum lateral stiffness for optimum ride, handling, and driving dynamics
- Built to help withstand potholes and designed to maximize seal life
- Dimensionally optimized to work with their mating parts
- Manufactured to GM OE specification for fit, form, and function
- This original equipment wheel bearing and hub assembly has been manufactured to fit your GM vehicle, providing the same performance, durability, and service life you expect from General Motors
Technical Specifications
| Specification | Value |
|---|---|
| MSRP | $221.62 - $247.44 (varies by retailer) |
| Condition | New |
| Fitment Type | Direct Replacement (OEM exact fit) |
| Material | High-quality steel (standard for GM OE hub assemblies) |
| ABS Compatibility | Equipped with ABS encoder ring, no sensor included |
| Number of Wheel Studs | 5 |
| Lug Bolt Thread Size | M12-1.50 |
| Wheel Pilot Diameter | 2.223 inches (56.46 mm) |
| Hub Pilot Diameter | 3.248 inches (82.50 mm) |
| Flange Bolt Hole Quantity | 5 |
| Flange Bolt Hole Diameter | 0.394 inches (10.00 mm) |
| Flange Diameter | 5.35 inches (136 mm) |
| Flange Offset | 2.55 inches (64.77 mm) |
| Brake Pilot Diameter | 2.36 inches (59.94 mm) |
| Item Dimensions | 7.9 x 7.7 x 7.4 inches |
| Item Weight | 7.46-7.60 lbs (3.38-3.45 kg) |
| UPC | 00808709627395 |
Important Notes
- This assembly includes wheel studs for easy installation
- Designed for both drum brake and disc brake configurations on specified Cruze models
- GM OE parts are built to help withstand potholes and designed to maximize seal life
- Backed by General Motors' minimum 12-month manufacturer warranty
- Manufactured to rigorous GM engineering standards to ensure optimal performance and safety
Vehicle Fitment Details (Specific Trims and Engines)
- 2016 Chevrolet Cruze: L, LS, LT, Premier (1.4L L4 - Gas)
- 2016 Chevrolet Cruze Limited: Eco, L, LS, LT, LTZ (1.4L L4 - Gas, 1.8L L4 - Flex, 1.8L L4 - Gas)
- 2015 Chevrolet Cruze: Diesel, Eco, L, LS, LT, LTZ (1.4L L4 - Gas, 1.8L L4 - Flex, 1.8L L4 - Gas)
- 2011-2014 Chevrolet Cruze: All trim levels with 1.4L L4 - Gas and 1.8L L4 - Gas engines
